Tokina Cinema 11-16mm T3 DX Lens

Loading
  • Tokina Cinema 11-16mm T3 DX Lens

Product options:

  • Parfocal Lens Design
  • Constant T3.0 Aperture
  • Geared Focus, Aperture, and Zoom Rings
  • De-Clicked Aperture Ring
  • Two Aspherical Lens Elements
  • Two Super-Low Dispersion Lens Elements
  • Multilayer Coating


Take It All In Without Taking a Step Back

The compact, lightweight Tokina Cinema 11-16mm T3.0 is not just a simple rehousing of the critically-acclaimed still lens version, rather the lens designers re-engineered it to provide cinematographers the control and performance they have come to expect in lenses that cost 10 times as much. Engineered to offer superb optical 4K performance the 11-16mm T3.0 delivers sharp, consistent images throughout its zoom range by reducing breathing and maintaining focus throughout the zoom range (Parfocal). Its compact size gives you the flexibilty to use it in creative ways not possible with larger lens designs.

FEATURES:

  • 166° focus throw on a super-wide angle zoom lens (PL mount model)
  • Proven ultra-wide angle optics have been converted to an 11-16 T3 cinema lens for use with APS-C, Super 35 and smaller image sensors
  • Parafocal optical design allow you to maintain precise focus while zooming
  • Reduced focus breathing so you an focus on the action unfolding and not the lens
  • 4K from the beginning with excellent sharpness and user controlled chromatic aberration
  • Two SD (Super-Low Dispersion) glass elements and two aspheric lenses allow our proprietary optical design to achieve excellent contrast and sharpness
  • Durable, compact all-metal cine-style housing with geared manual zoom, focus and aperture rings for use in follow-focus systems
  • Smooth, de-clicked, 9-bladed, curved iris
  • Virtually no image shift when using the focus or zoom control during filming


Lens Construction

MTF Chart

Focal Distance 11-16mm
Zoom Ratio 1.45:1
Optical Structure 11 groups /13 elements
Sensor Size Super 35mm
Minimum Focusing Distance 0.35m
Maximum Macro Magnification 1:11.6
Zoom Mode Rotary Zoom
Aperture/Iris Blades 9
Depth of Field T3.0 – T22 (F2.8 – F22)
Filter Size PL: 82mm, Canon EF, MFT:77mm
Overal Length
  • PL Mount: 103.3mm (from 86.5mm mount surface)
  • Canon EF Mount: 97.9mm (from 91.7mm mount surface)
  • Sony E Mount: 122.9mm (from 117.7mm mount surface)
  • MFT Mount: 120.7mm (from 116.5mm mount surface)
Diameter of Front Head PL: 85mm
Canon EF, Sony E, MTF: 84mm
Maximum Diameter PL: 85mm
Canon EF, Sony E, MTF: 84mm
Weight PL, Canon EF: 0.69kg /
Sony E: 0.81kg / MFT: 0.78kg
Lens Hood PL: NA
Canon EF, Sony E, MFT: BH-77A



Tokina Cinema 11-16mm T3.0 Lens

Brand: Tokina | Code: 1116CINEDXMFT

Product options:

Brand: Tokina | Code: 1116CINEDXMFT

At a glance

  • Parfocal Lens Design
  • Constant T3.0 Aperture
  • Geared Focus, Aperture, and Zoom Rings
  • De-Clicked Aperture Ring
  • Two Aspherical Lens Elements
  • Two Super-Low Dispersion Lens Elements
  • Multilayer Coating
