iFootage Motion S1A3 Bundle B0 (Without Battery)
- Wireless Time-Lapse & Panoramic Control
- Create 360° Panoramic Images
- Save Movements to 9 Tracks
- Supports Cameras up to 17.6 lb
Full Motion Wireless System
By combining Motion X2 and S1A1 mounted on a Shark slider S1, we managed to get a full motion wireless control system. It allows camera movements on two axis: 90° tilt and 360° pan. The system provides steady and automatic movements for time-lapses and shooting while panning as well as panoramas. Its main components are the wireless shutter controller, the electronic motor section, the wireless motorised controller and the Motion X2.
A Completely Programmable System
Just like S1A1, S1A3 is completely programmable being able to register up to 9 different tracks with pre-recorded movements. The tracks are easily accessible from the data packet and can be reused as needed. With repeated moves at different lengths of time, a wide range of visual effects can also be achieved easily. In addition, the S1A3 offers 'Manual Mode' which is perfect for run-and-gun style without losing precision. Its user friendly interface allows you to grab shots on-the-fly with no pre-programmed motion control.
Time Lapse and Stop Motion
iFootage Single Axis' strength is the time-lapse shoot and 360° panoramas. It controls the time-lapse by the number of stills as well as length of time. It has an Ease In/Out function and a Preview setting which helps users understand the video effect before shooting therefore increasing their success rate. Stop motion is also made easy with the S1A3. All you have to do is set up the number of frames and the time and then simply advance through each position to achieve a flawless end product. Our system perfectly integrates with Autopano, allowing you to create beautiful 360° panoramic images. Also, the system allows you to do simple parallax adjustments for various cameras.
360° Panoramas
Just like you would use the system for time-lapses, you could just as much use it to create beautiful 360° panoramic images, or videos with the ability to shoot in any angle. Autopano software is the perfect companion for a videographer that shoots panoramas.
Built-In Quality
The build quality of S1A3 is noticeable improved. It performs flawlessly in extreme environments withstanding even the harshest of conditions. Solid aluminium and quality craftsmanship are trademarks of iFootage products, and this system benefited fully from this. It is solid and sturdy, supporting a maximum load of 8kg. It has a working time of approximately 12 hours in a continuous video shoot or about 16 hours in time-lapse mode.
| Spin Speed | Motion X2: 0-40°/s |
| Speed Range | S1A1: 0.00039 to 6.3 in/sec (0.01 to 160 mm/sec) |
| Location Accuracy | Motion X2: 0.0025° S1A1: 0.00039 in (0.01 mm) |
| Load Capacity |
Motion X2: Optimum: 8.8 lb (4 kg) S1A1: Maximum: 17.6 lb (8 kg) |
| Motor Power |
Motion X2: 8-32 W S1A1: 8-32 W |
| Speed | Motion X2 Regulation: Stepless speed, Step speed |
| Operating Voltage |
Motion X2: 14.8~24 V S1A1 Output: 14.8~24 V Motor Module: 3.7 V Shutter Module: 3.7 V |
| Run Time (Up To) |
Motor Module: 50 hours Shutter Module: 50 hours |
| Remote Distance | 65.6' (20 m) |
| Pan & Tilt Battery Range |
Pan: 360° Tilt: 90° |
| Battery |
Motor Module: Lithium-ion (built-in, rechargeable) Shutter Module: 2 x AAA (LR6) |
| Maximum Battery Run Time |
Continuous Video: 12 hours Time-Lapse Mode: 16 hours |
| Material of Construction |
Aluminum |
| Weight |
Motion X2: 5.5 lb (2.5 kg) Motor Module: 14.8 oz (420 g) Shutter Module: 14.1 oz (400 g) |
| Product Manuals | |
|---|---|
| iFootage Motion S1A3 Bundle B0 (Without Battery) - Product Manual |
What's in the box:
- Pan & Tilt Head
- 75X50X10
- 2 x 1/4'' screw
- Plate base
- connection block A
- connection block B
- 4 x Club screw
- Power connection wire
- Limited Block
- 3/8'' screw
- 1/4''screw
- Antenna
- Electronic Motor Section
- Timing wheel
- 2 x Screw
- Wireless Motor Controller
- USB Connection
- 7 x Shutter Cable
- Handcase
- Instruction Manual
Brand: iFootage Equipment |
Code: IF-S1A3-B0
APN: 6957615910290 |
Supplier Code: 401000029
Brand: iFootage Equipment |
Code: IF-S1A3-B0
APN: 6957615910290 |
Supplier Code: 401000029
At a glance
- Wireless Time-Lapse & Panoramic Control
- Create 360° Panoramic Images
- Save Movements to 9 Tracks
- Supports Cameras up to 17.6 lb
|
Full motion wireless system By combining Motion X2 and S1A1 mounted on a Shark slider S1, iFootage managed to get a full motion wireless control system. |
 |
 |
A completely programmable system Just like S1A1, S1A3 is completely programmable being able to register up to 9 different tracks with pre-recorded movements. |
|
Time lapse and stop motion It controls the time-lapse by the number of stills as well as length of time. |
 |
 |
360° panoramas Just like you would use the system for time-lapses, you could just as much use it to create beautiful 360° panoramic images, or videos with the ability to shoot in any angle. |
