Kowa TE-9Z 20-60x Eyepiece for TSN-82SV & 660/600 Series Spotting Scope
$550.00
HURRY! Only 5 units left
- For Kowa 60mm, 66mm, & 82mm Scopes
- 20x-60x, 20x-60x, 20x-63x Magnification
- Long Eye Relief
Kowa's TE-9Z 20-60x Zoom Spotting Scope Eyepiece is compatible with TSN-82SV, TSN-660, and TSN-600 series spotting scopes to provide a wide magnification range that will satisfy most of your observational needs. Using a simple bayonet mount, it installs easily, and the knurled dial makes changing the zoom quick and sure. The TE-9Z features a wide apparent field of view – 42-126° with 60mm and 66mm scopes and 40-126° with the 82mm scope – and a 16/16.5mm eye relief value for comfortable glassing, even with eyewear.
| Magnification | 20-60x (TSN 600/660) 20-63x (TSN 82SV) |
| Exit pupil | 3.0-1.0mm (TSN 600) 3.3-1.1mm (TSN 660) 3.9-1.3mm (TSN-82SV) |
| Field of view at 1000M | 33.2-17.5M (TSN 600/660) 31-17M (TSN 82SV) |
| Eye relief | 16.5-16mm |
| Field of view | 1.9-1.0 degrees (TSN 600/660) 1.8-0.95 degrees (TSN 82SV) |
| Relative brightness | 9.0-1.0 (TSN 600) 10.9-1.2 (TSN 660) 6.8-1.7 (TSN 82SV) |
| Twilight Factor | 34.6-60.0 (TSN 600) 36.3-62.9 (TSN 660) 41.5-71.9 (TSN 82SV) |
| Weight | 370g |
Kowa TE-9Z 20-60x Zoom Spotting Scope Eyepiece
Brand: Kowa Optical Products |
Code: KWTE-9Z
APN: 4987067391615 |
Supplier Code: TE-9Z (TSE-Z9B)
Brand: Kowa Optical Products |
Code: KWTE-9Z
APN: 4987067391615 |
Supplier Code: TE-9Z (TSE-Z9B)
At a glance
- For Kowa 60mm, 66mm, & 82mm Scopes
- 20x-60x, 20x-60x, 20x-63x Magnification
- Long Eye Relief
