High-performance A1 planetary scanner. The ideal solution for professional digitization projects and service providers

The book2net Flash A1+ was specially developed for use in the mass digitization of large-format, bulky or particularly heavy originals such as magazine volumes.

The mass digitization of large-format books and documents is associated with a high throughput volume. This requires high productivity on the one hand, but also the greatest possible relief for the user at the workstation on the other.

For this reason, we have placed particular emphasis on streamlining the workflow when developing the book2net Flash.



High-performance sensor

  • High-performance area sensor
  • Selectable options: M70 (300 ppi) / M150 (400 ppi)
  • 0.3 sec. scanning time (A1 color at 300 ppi)
  • 2.2 sec. processing time (scannen + imaging + storage)
  • USB 3.0 interface
  • Optimized for OCR applications due to reduced signal noise


Optics

  • Schneider-Kreuznach precision lens
  • Depth of field 12 cm
  • Brilliant color rendering
  • Optical book fold optimization
  • Perfect linearity
  • Distortion-free
  • Long durability

LED illumination

  • Dual lighting unit (individually or synchronously controllable)
  • Cold light LEDs
  • Uniform illumination thanks to Fresnel lenses
  • Stepless regulation of the light emission angle
  • Constant wavelength
  • Stable color temperature
  • Light intensity <= 2,500 lux
  • Illumination time <= 0.6 sec.
  • Glare-free, UV/IR free (in accordance with EN60825-1)
  • Long service life (10,000 working hours)
  • Low energy consumption < 100 VA


Book cradle

  • Motorized book cradle with balancing technology
  • Height adjustment up to 25 cm
  • Spine exemption up to 25 cm
  • Double profile lifting columns for precise height adjustment
  • Load capacity up to 180 kg per column
  • Preservation approved

Fixed book table (optional)

  • Continuous supporting surface
  • Special coating on requirement


Motorized glass plate

  • Gentle on documents
  • Self-opening & self-closing
  • Format-dependent opening angle
  • Process-controlled pressure
  • Adjustable pressure sensitivity
  • Sensitive, fully electronic pressure control
  • Non-reflective glass (museum glass optional)


Semirobotics

  • PLC control with high-precision linear drive (1/100 mm precision)
  • Programmable scanning processes
  • Book size-dependent traverse paths
  • Adjustable opening angles
  • Process-controlled pressure
  • Sensitive, fully electronic pressure control
  • Variable control:
    • fully automatic
    • semi-automatic
    • manual
    • time-controlled
    • user-controlled


Software & Features

  • Live Video Preview
  • Easy Scan / bookScan professional scanning software
  • OCR (optional)
  • Live Control Professional (optional)


Color management

Integrated true color management:
METAMORFOZE, FADGI, ISO/TS 19264:1 2017 standard regarding color quality, resolution, noise & linearity



Eco-friendly

  • No UV / IR radiation
  • No ozone, no emissions
  • No heat load
  • Lowest noise emission
  • Low-Energy-Control (LEC)
  • Energy-saving
