Vanguard Endeavor HD 82A 20-60x82 Angled Spotting Scope
- Angled View Eyepiece
- 20-60x Eyepiece Magnification
- Extra-Low Dispersion Glass Elements
- Fully Multicoated Optics
- Nitrogen-Filled Fogproof / Waterproof
- Magnesium Housing
- Tripod Mounting Shoe
- Rubber Armored Body
- Stacked Fine / Coarse Focus Controls
- Built-In Sunshield
The Vanguard Endeavor HD 82A 20-60x82 Angled Spotting Scope employs extra-low dispersion glass (ED) to ensure accurate color rendition and virtually eliminate color fringing.
This version of the Endeavor HD spotting scope includes a 20-60x zoom eyepiece featuring a rubber zoom dial. A 1:3 zoom ratio and 2.1-1.0° angle of view complement the eyepiece's long 19mm eye relief and rubber eyecup, which help to provide additional viewing comfort for long-duration observations.
In addition to the image quality and weather-sealed construction, the Endeavor HD includes several features that enhance the scope's functionality. A stacked dual-focus mechanism enables the observer to make fine and coarse focus adjustments. The tripod mounting foot has a standard 1/4" socket and is compatible with Vanguard tripods that accept the universal mounting shoe. An integrated sunshade and included custom fit raincoat carrying case help to make the Endeavor HD a full-featured spotting scope for outdoor use.
Optical Performance
- 20-60x magnification, 82mm objective
- Extra-low dispersion glass elements, BaK4 prisms
- Fully multicoated optics
- 2.1-1.0° angle of view
- 19.7 ft close focus distance (at 20x)
-
Use and Handling
- Angled view eyepiece is inclined 45° from the objective lens
- Separate coarse / fine focus controls
- Interchangeable eyepiece mount
- Tripod mounting foot
-
Construction Details
- Nitrogen-filled fogproof / waterproof housing
- Magnesium body with textured rubber armor
- Built-in sunshield
| WARRANTY | Applicable by national law |
|---|---|
| BODY MATERIAL | Magnesium alloy |
| COLOR | Black |
| DIAMETER OF OBJECTIVES | 82mm |
| DIMENSIONS (L X W) | 380 x 180 mm |
| EYE CUP | Twist out |
| FIELD OF VIEW @1000M | 37~ 17 |
| FOCUS SYSTEM | Center focus |
| LENS COATING | Fully multi coated |
| NEAR FOCUS (M) | 6 ~ 6.50 |
| OCULAR ADJUSTMENT | ± 0 |
| PHASE COATING | YES |
| POWER | 20 ~ 60 |
| PRISM TYPE | BaK4 prism |
| RELATIVE BRIGHTNESS | 16.8~1.8 |
| TWILIGHT FACTOR | 40.4~70.1 |
| VIEW ANGLE | 2.1 ~ 1.0 |
| WATERPROOF | Yes |
| WEIGHT (G) | 1810 |
| WEIGHT (OZ) | 63.8 |
Brand: Vanguard |
Code: V237992
APN: 4719856237992 |
Supplier Code: V237992
Brand: Vanguard |
Code: V237992
APN: 4719856237992 |
Supplier Code: V237992
At a glance
- Angled View Eyepiece
- 20-60x Eyepiece Magnification
- Extra-Low Dispersion Glass Elements
- Fully Multicoated Optics
- Nitrogen-Filled Fogproof / Waterproof
- Magnesium Housing
- Tripod Mounting Shoe
- Rubber Armored Body
- Stacked Fine / Coarse Focus Controls
- Built-In Sunshield
