Rayzr 7 300 Daylight Premium Pack 7" LED Fresnel Light inc Barn Doors and case

$3,200.00 ETA: 21/01/2025

Daylight 5,600 K
LED power 300 W
Beam angle 18° - 55°
Battery 24 - 36 V DC
Advanced Vapor Cooling System

The new Rayzr 7 300 Daylight is the brightest fixture of the Rayzr 7 series. With 300 Watt of high powered quality (TLCI up to 98) LED’s in a compact and lightweight housing with a 7” fresnel, you get one of the brightest, and yet one of the most mobile LED fresnels on the market. The all new Rayzr 7.

LED Power	300 W
Beam Angle	18° - 55° (Half Peak Angle)
White Light	Daylight 5,600 K
Color Temperature Tolerance	+/- 150 K (nominal)
Color Rendition	TLCI 95 ~ 98, CRI 94 ± 2
Dimming	0 -100% Continuous
Control	RJ-45 DMX In and Through, On-Board Controller
Estimated LED Lifetime	50,000 hours (15 Years of average use)
Power Voltage Range	180-264 V AC, 50-60 Hz (EU) 90-132 V AC, 50-60 Hz (US)
Input Current Range	Max. 2.0A@180V, 1.3A@264V Max. 3.9A@90V, 2.7A@132V
Power Consumption	331 W Nominal 352 W Maximum
Power Connection	Neutrik power CON TRUE1 NAC3MPX; Plug: Neutrik power CON TRUE1 NAC3FX-W
Battery DC Power Voltage Range	24 - 36 V DC
Battery DC Input Current Range	Max. 13.75A@24V 9.17A@36V
Battery DC Power Consumption	311 W Nominal 330 W Maximum
Battery DC Power Connection	Neutrik speak ON NL2MP; Plug: Neutrik speak ON NL2FX
Optical System	Focusable Fresnel
Lens Diameter	170 mm / 6.7 inch
Thermal Design	Advanced Vapor Cooling System
Mounting	16 mm / 28 mm Combo Pin (Baby 5/8 inch / Junior 1-1/8 inch Combo Pin)
Tilt Angle	+/- 90°
Housing Color	Black
Ambient Temperature Operation	-20 to +45º C (-4 to +113º F)
Protection Class	IP 20
Certifications	CE, FCC, RoHS, REACH

Datasheets
	Rayzr 7 300 Daylight Premium Pack 7" LED Fresnel Light inc Barn Doors and case - Datasheet
Product Manuals
	Rayzr 7 300 Daylight Premium Pack 7" LED Fresnel Light inc Barn Doors and case - Product Manual

What's in the box:

Rayzr 7 7" 300W Daylight LED Fresnel Light
Power Supply
4-Leaf Barndoor for Rayzr 7 LED Fresnel
Travel Case
Limited 1-Year Warranty
