Rayzr 7 300B Bi-Color 7" LED Fresnel Light

$3,334.00 ETA: 22/12/2024

Bi-color 3,200 K to 5,600 K
LED power 150 W + 150 W
Beam angle 18° - 50°
Battery 24 - 36 V DC
Advanced Vapor Cooling System

The new Rayzr 7 300B Bi-color combines a very bright light with the ability to seamlessly transition color temperature between 3,200 K and 5,600 K, without losing the intensity of the light or sacrificing the smoothness of the light field. Like all Rayzr 7 lights it is designed for maximum workflow. Quickly set it up, adjust the settings and enjoy all the benefits of LED.

LED Power	150 W + 150 W
Beam Angle	18° - 50° (Half Peak Angle)
White Light	Bi-color 3,200-5,600 K Continuously Variable CCT
Color Temperature Tolerance	+/- 150 K (nominal)
Color Rendition	TLCI 95 ~ 98, CRI 94 ± 2
Dimming	0 -100% Continuous
Control	RJ-45 DMX In and Through, On-Board Controller
Estimated LED Lifetime	50,000 hours (15 Years of average use)
Power Voltage Range	90-264 V AC, 50-60 Hz
Input Current Range	Max. 2.2A@90V 0.73A@264V
Power Consumption	172 W Nominal 192 W Maximum
Power Connection	Neutrik power CON TRUE1 NAC3MPX; Plug: Neutrik power CON TRUE1 NAC3FX-W
Battery DC Power Voltage Range	24 - 36 V DC
Battery DC Input Current Range	Max.6.9A@24V 4.5A@36V
Battery DC Power Consumption	162 W Nominal 180 W Maximum
Battery DC Power Connection	Neutrik speak ON NL2MP; Plug: Neutrik speak ON NL2FX
Optical System	Focusable Fresnel
Lens Diameter	170 mm / 6.7 inch
Thermal Design	Advanced Vapor Cooling System
Mounting	16 mm / 28 mm Combo Pin (Baby 5/8 inch / Junior 1-1/8 inch Combo Pin)
Tilt Angle	+/- 90°
Housing Color	Black
Ambient Temperature Operation	-20 to +45º C (-4 to +113º F)
Protection Class	IP 20
Certifications	CE, FCC, RoHS, REACH

Datasheets
	Rayzr 7 300B Bi-Color 7" LED Fresnel Light - Datasheet
Product Manuals
	Rayzr 7 300B Bi-Color 7" LED Fresnel Light - Product Manual

What's in the box:

Rayzr 7 7" 300W Bi-Color LED Fresnel Light
Power Supply
Limited 1-Year Warranty

Related Categories

Brand: Rayzr 7 | Code: 123050021210
APN: 4250972500930 | Supplier Code: 123050021210

At a glance

Bi-color 3,200 K to 5,600 K
LED power 150 W + 150 W
Beam angle 18° - 50°
Battery 24 - 36 V DC
Advanced Vapor Cooling System
