A Waterproof, Dustproof,Heavy-Duty Digital Camera |
![]() |
|
![]() |
||
Proof Against Water, Dust,Shock and Chemicals *1 |
5× Optical Zoom(28–140 mm) *2 |
Support ForCamera Memos |
Use the camera or a PC to create written or voice memos that can later be added to photos. Memos can contain up to 30 seconds of audio or up to 100 items with descriptions of up to 128 characters each.
A previously-recorded image of a survey slate can be embedded as sub-image to a photo of the entire worksite, making it easier to take photos when your hands are too full, or the location too cramped or too dark, to place a slate. You can also choose the slate’s size (large, medium, or small) and location (up, down, left, or right).
Use existing pictures as a template when composing new photos. Template transparency can be selected from 20, 40, 60, and 80 percent. Templates can also be placed next to photos with the same composition for side-by-side comparisons. One way in which this feature can be used is for before and after shots on construction sites.
Ring LightThe lens is surrounded by a six-LED Ring Light. You can choose which LEDs light and adjust their brightness to get clear shots showing fine details such as the model numbers on small parts or scratches in walls or floors.
Use the camera’s built-in GPS and electronic compass to record location data with photos and movies. Location data can be acquired via GPS, the Japanese Quasi-Zenith Satellite System (QZSS, also known as Michibiki), and GLONASS. The “GPS Lock” button can be used to record the location of a selected target.
Shoot movies in 4K (frame size 3840 × 2160 pixels, 30 fps) for high-resolution footage that gives you an overall view of a big construction site, for example, or helps you grasp the relative positions of various objects.
The camera features internal memory with space enough for 856 maximum-quality images. Keep shooting secure in the knowledge that won’t run out of storage when the memory card is full.
Password-protect access to any or all camera features, including camera controls, menus access, internal memory viewing, and USB connection. Choose separate administrator and user passwords for greater control over security. Access can be granted by scanning a password barcode or entering the password using the camera’s onscreen keyboard.
Imaging |
|
|
Pixels |
20 Megapixel |
|
Aspect Ratio |
1:1, 3:2, 4:3 |
|
Sensor Type |
CMOS |
|
Sensor Size |
1/2.3" |
|
Image File Format |
JPEG |
|
Image Stabilization |
Digital |
Lens |
|
|
Focal Length |
5 to 25mm (35mm Equivalent Focal Length: 28 to 140mm) |
|
Optical Zoom |
5x |
|
Digital Zoom |
8.1x Maximum (40.5x Combined Zoom) |
|
Maximum Aperture |
f/3.5 to 5.5 |
|
Focus Range |
Normal |
|
Optical Design |
11 Elements in 9 Groups |
Exposure Control |
|
|
ISO Sensitivity |
Auto, 125 to 25600 |
|
Shutter Speed |
Electronic Front Curtain Shutter |
|
Metering Method |
Center-Weighted Average, Multi, Spot |
|
Exposure Modes |
Program |
|
Exposure Compensation |
-2 to +2 EV (1/3 EV Steps) |
|
White Balance |
Auto, Cloudy, Daylight, Fluorescent (Day White), Fluorescent (Daylight), Fluorescent (White), Manual, Ring Light, Shade, Tungsten |
|
Interval Recording |
Yes |
Video |
|
|
Recording Modes |
H.264 |
|
Recording Limit |
Up to 25 Minutes |
|
Video Encoding |
NTSC |
|
Audio Recording |
Built-In Microphone |
Viewfinder and Monitor |
|
|
Monitor Size |
3" |
|
Monitor Resolution |
1,040,000 Dot |
|
Monitor Type |
LCD |
Flash |
|
|
Built-in Flash |
Yes |
|
Flash Modes |
Flash On, Off, Red-Eye Reduction |
|
Effective Flash Range |
ISO Auto |
|
External Flash Connection |
None |
Interface |
|
|
Memory Card Slot |
1 x SD/SDHC/SDXC |
|
Internal Memory |
6.5 GB |
|
Connectivity |
HDMI D (Micro), USB 3.0, USB Type-C |
|
Wireless |
None |
|
GPS |
Yes |
Environmental |
|
|
Waterproof |
65.6' / 20 m |
|
Shockproof |
6.6' / 2 m |
|
Crushproof |
220 lbf / 100 kgf |
|
Operating Temperature |
14 to 104°F / -10 to 40°C |
Physical |
|
|
Battery |
1 x DB-110 Rechargeable Lithium-Ion, 3.6 VDC, 1350 mAh |
|
Dimensions (W x H x D) |
4.7 x 2.6 x 1.3" / 118.2 x 65.5 x 33.1 mm |
|
Weight |
8.71 oz / 247 g (Body with Battery and Memory) |
