Zeiss CP.3 35mm T2.9 PL feet XD eXtended Data 2177894

OVERVIEW

Digital technologies have transformed traditional filmmaking and refashioned the market. New and innovative technologies in both production and post-production have paved the way for a more versatile, cost effective and advanced workflow. The ZEISS CP.3 family is the latest contribution from ZEISS to support creative and progressive filmmaking with an affordable, future-proof and premium quality lens set.

The ZEISS CP.3 lenses offer the perfect combination of high image quality and reliable usability. They exhibit the clean, crisp characteristics ZEISS is known for, together with an interchangeable mount system and full-frame coverage. The ZEISS CP.3 XD version features innovative and ground-breaking lens data technology to speed-up and simplify the workflow on set and in post-production.

The ZEISS eXtended Data is a unique technology which is based on the /i* Technology and provides information about the lens’ distortion and shading characteristics in real time. With the ZEISS CP.3 XD lenses, even small productions on a limited budget gain access to the advanced techniques common in state-of-the-art, big budget films, commercials and television shows.

Sample Videos

The Floor is Lava ZEISS Compact Prime CP.3 and CP.3 XD Lenses Three roommates must survive when the floor... is lava! ‘The Floor is Lava’ is a viral sensation which was filmed with the help of ZEISS CP.3 XD lenses. These new cinema prime lenses have metadata capabilities that allow filmmakers to achieve a higher quality image for VFX and other applications.

	The Floor is Lava \| Behind the Scences ZEISS Compact Prime CP.3 and CP.3 XD Lenses A Behind-The-Scenes explanation of how CP.3 XD lenses along with a lens metadata workflow was used in the making of this video. Three roommates must survive when the floor... is lava! ‘The Floor is Lava’ is a viral sensation which was filmed with the help of ZEISS CP.3 XD lenses. These new cinema prime lenses have metadata capabilities that allow filmmakers to achieve a higher quality image for VFX and other applications.

Case 10-86 - Behind the Scenes ZEISS Compact Prime CP.3 and CP.3 XD Lenses Visual effects specialist, producer and director Scott E. Anderson had a chance to test the ZEISS Compact Primes CP.3 XD lenses for the first time. This reel will walk you through the different steps in creating a visual effects piece on a budget using ZEISS eXtended Data. The ZEISS eXtended Data is a unique technology which is based on the /i Technology and provides information about the lens’ distortion and shading characteristics in real time. With the ZEISS CP.3 XD lenses, even small productions on a limited budget gain access to the advanced techniques common in state-of-the-art, big budget films, commercials and television shows.

	Case 10-86 \| Showreel ZEISS Compact Prime CP.3 and CP.3 XD Lenses Digital technologies have transformed traditional filmmaking and refashioned the market. New and innovative technologies in both production and post-production have paved the way for a more versatile, cost effective and advanced workflow. The ZEISS Compact Prime CP.3 family is the latest contribution from ZEISS to support creative and progressive filmmaking with an affordable, future-proof and premium quality lens set. Visual effects specialist, producer and director Scott E. Anderson had a chance to test the ZEISS Compact Prine CP.3 XD lenses for the first time.

Exploring the beauty of Wales ZEISS Compact Prime CP.3 and CP.3 XD Lenses New ZEISS CP.3 showreel exploring the beauty of Wales, United Kingdom. Shot with: ► ZEISS Compact Prime CP.3 18mm / T2.9 ► ZEISS Compact Prime CP.3 35mm / T2.1 ► ZEISS Compact Prime CP.3 50mm / T2.1 We recommend to watch the video in 4K (3840 × 2160).

	Chemist - Artist - Architect \| Behind the Scenes ZEISS Compact Prime CP.3 and CP.3 XD Lenses The movie “Chemist – Artist – Architect” narrates a passion. Christoph Filsers‘ inner voice describes something intimate. “Chemist” stands for the procedure coloring the hair, “Artist” refers to the imagination of styling a coiffure matching the personality and “Architect” describes the symmetry during the hair cutting which must fit precisely. If the three merge into one, trust can last a life-time.

Chemist - Artist - Architect ZEISS Compact Prime CP.3 and CP.3 XD Lenses The movie “Chemist – Artist – Architect” narrates a passion. Christoph Filsers‘ inner voice describes something intimate. “Chemist” stands for the procedure coloring the hair, “Artist” refers to the imagination of styling a coiffure matching the personality and “Architect” describes the symmetry during the hair cutting which must fit precisely. If the three merge into one, trust can last a life-time. We recommend to watch the video in 4K (3840 × 2160).

FEATURES

True cine look details Ranging from 15 mm to 135 mm, the ten focal lengths available in the ZEISS Compact Prime CP.3 or CP.3 XD series cover all applications from wide-angle to telephoto. The ZEISS CP.3 lenses feature advanced lens coatings, painted lens rims and special light traps within the barrel to eliminate unwelcome veiling glare and flares. The result is higher contrast, richer blacks and more saturated colors. ► Clean and crisp ZEISS look which matches perfectly with other ZEISS cinema lenses. ► Color matching and covering full frame across the full range of focal lengths from 15 to 135 mm. ► Special lens coatings support high-dynamic range projects.
	New ZEISS eXtended Data technology details The ZEISS eXtended Data technology adds new opportunities to simplify and increase the accuracy of the image capture and processing workflow. ZEISS eXtended Data unifies two data sets: key lens data based on the open /i* Technology standard and supported by a wide range of cameras and accessories, plus ZEISS specific lens data that contains precise lens characteristics. ► A unique technology that provides information about the lens’ distortion and shading characteristics in real time to speed-up the workflow on set and in post-production. ► Lens settings are digitally captured on every frame, avoiding the need to manually record the lens settings for every shot. ► Documentation of the lens’ characteristics enhances creativity by allowing more complex shots to be handled in post-production.
Ultimate cine ergonomics details The ZEISS CP.3 lenses are a professional toolset that simplifies your work on set. They are easy to handle, allow for fast changeover of equipment and give you great creative freedom to make your ideas come to life. ► Standardized positioning of the focus rings and a consistent 95 mm front diameter allows for fast and easy changeover while on set. ► Extraordinarily smooth focus rotation even in extreme temperature conditions thanks to a new, sophisticated construction design. ► Consistent T-stops simplifies lighting on set and exposure compensations (T2.9 for 15 to 21 mm and T2.1 for 25 to 135 mm).
	Compactness redefined details The compact and light-weight design enables you to use different stabilizing systems and to have a compact camera setup that is ideal for shooting in narrow spaces and for capturing dynamic shots. ► The compact and light-weight design is ideal for handheld, gimbal, drone and Steadicam applications. ► Consistent size and weight across most of the focal lengths enables quick change of lenses when used on drones and gimbals. ► The ultra-smooth focus rotation allows use of small focus motors.

SPECIFICATIONS

Mount	PL
Focal Length	35mm
Aperture	T2.1 to T22
Close Focus Distance	12 / 30 cm
Image Circle	43.2 mm
Focus Rotation	300°
Iris Blades	15
Front Lens Diameter	95 mm
Focus Scales	Feet
Length	3.3 / 83.7 mm
Weight	1.8 lb / 0.8 kg

DOWNLOADS

2177894 - Brochure

2177894 – Spec Sheet

2177894 – User Manual

IN THE BOX

Zeiss CP.3 XD 35mm T2.1 Compact Prime Lens (PL Mount, Feet)
