Pentax ZD 10x43 WP Binoculars
- Phase-Corrected BAK4 Roof Prisms
- Hybrid Aspherical Lens Elements
- Fully Multicoated Optics
- Wide Angle of View: 60°
- Nitrogen-Filled, Water and Fogproof
- Closed Bridge Configuration
- Magnesium Alloy Chassis
- Knurled Center Focus Wheel
- Tripod Mountable
- Twist-Up Eyecups
The Pentax 10x43 Z-Series ZD WP Binocular features multiple optical technologies to improve the image quality and ensure accurate colors in all weather and lighting conditions.
The image-enhancement starts with hybrid aspherical lens elements that eliminate distortion around the edges of the lens for clear edge-to-edge views and corrects lens astigmatism that can prevent the ability to bring subjects into sharp focus. Anti-reflection fully multicoated optics maximize light transmission through the entire optical path to make views appear bright and crisp, especially in low light. Finally, the BAK4 roof prisms are phase-corrected to enhance contrast and further correct chromatic aberration. These technologies work together to produce bright and clear high-contrast images with accurate colors and virtually no distortion.
Complementing the optical performance is a housing that is built for a lifetime of rugged outdoor use. The chassis is made of a lightweight and durable magnesium alloy with a rubberized armor that protects against impacts while providing a slip-resistant grip. The optical tubes are nitrogen filled for fogproof performance and O-ring sealed to make the binocular submersible to as much as 3.3. An protective external lens coating helps to repel dust, water, and oil to ensure obstruction-free viewing. For longer glassing sessions, they are tripod mountable with an optional adapter.
|
Prism Type |
Roof |
|
Magnification |
10x |
|
Objective Lens Diameter |
43mm |
|
Angle of View |
6.0° (actual) |
|
Field of View |
315.0 @ 1000 yd / 105.0 m @ 1000 m |
|
Minimum Focus Distance |
42.7 / 1.1 m |
|
Exit Pupil Diameter |
4.3 mm |
|
Eye Relief |
17 mm |
|
Focus Type |
Center |
|
Tripod Mount |
Yes (Adapter Optional) |
|
Dimensions |
5.7 x 5.0 x 2.0 / 14.5 x 12.7 x 5.1 cm |
|
Weight |
25.0 oz / 708.8 g |
Brand: Pentax |
Code: 62722
APN: 0027075288560 |
Supplier Code: 62722
Brand: Pentax |
Code: 62722
APN: 0027075288560 |
Supplier Code: 62722
