X-Rite i1Publish Pro 3

Aperture

Measurement aperture: 4.5 mm (0.18”) diameter (effective measurement aperture during scanning is depending on the patch size and measurement speed)

Available Disk Space

2GB

Calibration

Manual on external ceramic white reference (included)

Communication Interface

USB 1.1

Connectivity

Powered USB port

Dimensions (length, width, height)

i1Pro device: 162 mm x 69 mm x 64 mm (6.4” x 2.7” x 2.5”)

Display Resolution

1024x768 pixels or higher

Experience Level

Intermediate to Advanced

Humidity

30 to 85% RH (non-condensing)

Illumination Spot Size

3 mm (0.12”)

Inter-Instrument Agreement

0.3 dE00 avg, 0.8 dE00 max (deviation from X-Rite manufacturing standard at a temperature of 23ºC (73.4ºF) on 12 BCRA tiles (D50, 2º))

Internet Connection

Required for software install, download and automatic update

Languages Supported

Chinese (Simplified), English, French, German, Italian, Japanese, Korean, Portuguese, Spanish

Light Source

i1Pro3 Plus LED Illumination (including UV)

Macintosh

MacOS X 10.11x, 10.12x, 10.13x, 10.15 (with latest upgrades installed)

Measurement Conditions

• M0 - UV included - ISO 13655:2017
  • M1 - D50 - ISO 13655:2017
  • M2 - UV excluded Filter - ISO 13655:2017

Measurement Frequency in Scanning Mode

400 measurements per second

Measurement Geometry

45°/0° ring illumination optics, ISO 13655:2017

Media Thickness

1mm or less

Memory

2GB Minimum

Number of Displays Supported per Workstation

Up to 4

Operating Temperature Range

10°C to 35°C
50°F to 95°F

Patch Size

Minimal Patch Size in Scanning Mode: 7 x 7  mm (0.28” x 0.28”) (Width x Height) with sensor ruler 10 x 7 mm (0.40” x 0.28”) (Width x Height) without sensor ruler

Photometric Range

10nm; Sampling interval 3.5nm

Processor

MAC: Intel® Core 2 Duo CPU or better; WINDOWS: Intel® Core 2 Duo or AMD Athlon™ XP or better

Scan Length

Maximum 260mm (10.24")

Scanner Target Support

Yes

Scanning Capability

Yes

Security

User must have Administrator rights to install and uninstall the application

Short Term Repeatability - White

0.05 dE00 on white (D50,2°, mean of 10 measurements every 3 seconds on white)

Single Pass Scan

Yes

Software Development Kit

Available for OEM customers

Software Modes

Basic & Advanced

Spectral Analyzer

i1® technology with built-in wavelengths check; Holographic diffraction grating with 128-pixel diode array

Spectral Range

380 - 730 nm

Spectral Reporting

380 ... 730 nm in 10 nm steps

Storage Temperature Range

-20° to 50°C
-4° to 122°F

Supported Profile Format

ICC version 2, version 4.3,  & iccMax

Unit Color

Black/Silver

User Experience

Choose between a ‘basic’, wizard-driven interface or an ‘advanced’, user-driven interface for highest level professional results

Video Card

MAC: Latest drivers for video card installed;

WINDOWS: Latest drivers for video card installed, dual display support requires either 2 video cards or a dual head video card that supports dual video LUTs being loaded

Warranty

Twelve (12) months from the date of sale, unless different local regulations apply. Product registration is required to receive X-Rite technical support during the warranty period. Registration can occur directly through the software, on our website, or via phone. Users are encouraged to register their product within the first 30 days of use.

Weight

i1Pro device: 285 g (10.1 oz)
