iFootage Mini Crane M1-III with free M1 Low Profile Quick Release Adapter
- Features Tilt & Hold technology
- Newly added damping function
- Flexible mounting options
- New quick and secure locking system
The M1-III Mini Cranefrom iFootage is a compact, portable jib arm featuring lightweight carbon-fiber construction, a telescoping square-arm tube, and multiple mounting options. Its square tube design helps to minimize potential shaking during operation. The M1-III has a maximum payload of 33 lb in standard mode and 22 lb in low-angle mode. The main jib arm and the counterweight arm each have one telescoping stage (two sections) with locking thumb-lever knobs. Standard barbell weights (available separately) may be used as counterweights.
Mount your DSLR (or other small camera) on either of two included quick release plates: the M1 or the Motion X2. The M1 plate has both a flat camera plate and a ball mount, enabling use of a fluid head (with a 60 or 75mm ball). The Motion X2 plate is used with micro cameras or when using wide- angle lenses. Both the arm base and the camera base incorporate 1/4"-20 & 3/8"-16 holes for mounting accessories.
The adjustable tilt-damping knob, the tilt lock, and the pan drag function give you added control over your crane shots. For programmable moves, the M1-III can be used with the iFootage Motion X2 or other motion control systems.
- 33 lb load capacity in standard mode, 22 lb in low mode
- Lightweight, carbon fiber, telescoping square-tubed main arm
- Compatible with 75mm ball or flat base–tripod heads
- Locking, damping-controlled tilt function, and pan drag control
- Camera can be mounted using the included quick-release plate or via a 60 or 75mm bowl head
- Quick-release plates have both 1/4"-20 & 3/8"-16 threaded holes
- Accessories can be mounted to the arm base and the camera base via 1/4"-20 & 3/8"-16 threaded holes
- Standard barbell weights can be used as counterweights
Material |
Carbon Fiber Anodised Aluminium |
Weight |
3.8kg |
Tube Diameter |
43x40mm |
Extended Length |
2170±20mm |
Folded Length |
70±20mm |
Max Radius |
1200mm |
Tilt Length |
2100mm |
Low Angle Load |
10kg |
Max Load |
15kg |
Product Manuals | |
---|---|
iFootage Mini Crane M1-III with free M1 Low Profile Quick Release Adapter - Product Manual |
What's in the box:
- Main Section
- Fixing Screw
- 2.5" Hex Keys
- Locking Knob
- Standard Quick Release Plate (For Motion X2)
- M1 Quick Release Plate
- Carrying Case
- Warranty Card
- Instruction Manual
- Product Certification
- Counterweight Clamp
Note: Low Profile Quick Release Adapter is not included.
Requires iFootage Wildbull tripod.
Brand: iFootage Equipment |
Code: IF-MC3
APN: 6957615910320 |
Supplier Code: 401000032
Brand: iFootage Equipment |
Code: IF-MC3
APN: 6957615910320 |
Supplier Code: 401000032
