Rayzr 7 300B Bi-Color 7" LED Fresnel Light

Rayzr 7 300B Bi-Color 7" LED Fresnel Light

Code: 123050021210    Brand: Rayzr 7
  • Bi-color 3,200 K to 5,600 K
  • LED power 150 W + 150 W
  • Beam angle 18° - 50°
  • Battery 24 - 36 V DC
  • Advanced Vapor Cooling System
 IN STOCK
$2,748.90
APN: 4250972500930
Supplier Code: 123050021210

The new Rayzr 7 300B Bi-color combines a very bright light with the ability to seamlessly transition color temperature between 3,200 K and 5,600 K, without losing the intensity of the light or sacrificing the smoothness of the light field. Like all Rayzr 7 lights it is designed for maximum workflow. Quickly set it up, adjust the settings and enjoy all the benefits of LED.

LED Power 150 W + 150 W
Beam Angle 18° - 50° (Half Peak Angle)
White Light Bi-color 3,200-5,600 K
Continuously Variable CCT
Color Temperature Tolerance +/- 150 K (nominal)
Color Rendition TLCI 95 ~ 98, CRI 94 ± 2
Dimming 0 -100% Continuous
Control RJ-45 DMX In and Through, On-Board Controller
Estimated LED Lifetime 50,000 hours (15 Years of average use)
Power Voltage Range 90-264 V AC, 50-60 Hz
Input Current Range Max. 2.2A@90V
0.73A@264V
Power Consumption 172 W Nominal
192 W Maximum
Power Connection Neutrik power CON TRUE1 NAC3MPX;
Plug: Neutrik power CON TRUE1 NAC3FX-W
Battery DC Power Voltage Range 24 - 36 V DC
Battery DC Input Current Range Max.6.9A@24V
4.5A@36V
Battery DC Power Consumption 162 W Nominal
180 W Maximum
Battery DC Power Connection Neutrik speak ON NL2MP; Plug:
Neutrik speak ON NL2FX
Optical System Focusable Fresnel
Lens Diameter 170 mm / 6.7 inch
Thermal Design Advanced Vapor Cooling System
Mounting 16 mm / 28 mm Combo Pin (Baby 5/8 inch / Junior 1-1/8 inch Combo Pin)
Tilt Angle +/- 90°
Housing Color Black
Ambient Temperature Operation -20 to +45º C (-4 to +113º F)
Protection Class IP 20
Certifications CE, FCC, RoHS, REACH

What's in the box:

  • Rayzr 7 7" 300W Bi-Color LED Fresnel Light
  • Power Supply
  • Limited 1-Year Warranty
This product has yet to be reviewed

To be the first to review this product simply fill out the form to the left and let us know how you feel about this product!


To estimate the freight on this item simply enter the destination postcode and the desired quantity and click the "estimate" button.

OVERVIEW

The new Rayzr 7 300B Bi-color combines a very bright light with the ability to seamlessly transition color temperature between 3,200 K and 5,600 K, without losing the intensity of the light or sacrificing the smoothness of the light field. Like all Rayzr 7 lights it is designed for maximum workflow. Quickly set it up, adjust the settings and enjoy all the benefits of LED.

SPECIFICATIONS

LED Power 150 W + 150 W
Beam Angle 18° - 50° (Half Peak Angle)
White Light Bi-color 3,200-5,600 K
Continuously Variable CCT
Color Temperature Tolerance +/- 150 K (nominal)
Color Rendition TLCI 95 ~ 98, CRI 94 ± 2
Dimming 0 -100% Continuous
Control RJ-45 DMX In and Through, On-Board Controller
Estimated LED Lifetime 50,000 hours (15 Years of average use)
Power Voltage Range 90-264 V AC, 50-60 Hz
Input Current Range Max. 2.2A@90V
0.73A@264V
Power Consumption 172 W Nominal
192 W Maximum
Power Connection Neutrik power CON TRUE1 NAC3MPX;
Plug: Neutrik power CON TRUE1 NAC3FX-W
Battery DC Power Voltage Range 24 - 36 V DC
Battery DC Input Current Range Max.6.9A@24V
4.5A@36V
Battery DC Power Consumption 162 W Nominal
180 W Maximum
Battery DC Power Connection Neutrik speak ON NL2MP; Plug:
Neutrik speak ON NL2FX
Optical System Focusable Fresnel
Lens Diameter 170 mm / 6.7 inch
Thermal Design Advanced Vapor Cooling System
Mounting 16 mm / 28 mm Combo Pin (Baby 5/8 inch / Junior 1-1/8 inch Combo Pin)
Tilt Angle +/- 90°
Housing Color Black
Ambient Temperature Operation -20 to +45º C (-4 to +113º F)
Protection Class IP 20
Certifications CE, FCC, RoHS, REACH

IN THE BOX

What's in the box:

  • Rayzr 7 7" 300W Bi-Color LED Fresnel Light
  • Power Supply
  • Limited 1-Year Warranty
