Vanguard Vesta 560A 15-50x60 Angled-DIx Spotting Scope - Includes case & tripod

Loading
  • Vanguard Vesta 560A 15-50x60 Angled-DIx Spotting Scope - Includes case & tripod
  • Vanguard Vesta 560A 15-50x60 Angled-DIx Spotting Scope - Includes case & tripod
  • Vanguard Vesta 560A 15-50x60 Angled-DIx Spotting Scope - Includes case & tripod
  • Vanguard Vesta 560A 15-50x60 Angled-DIx Spotting Scope - Includes case & tripod
  • Vanguard Vesta 560A 15-50x60 Angled-DIx Spotting Scope - Includes case & tripod
  • Vanguard Vesta 560A 15-50x60 Angled-DIx Spotting Scope - Includes case & tripod
  • Vanguard Vesta 560A 15-50x60 Angled-DIx Spotting Scope - Includes case & tripod
$395.00 In Stock

  • 45° Angled Viewing
  • 15-45x Zoom Eyepiece
  • 60mm Objective Lens
  • Advanced MultiGuard Lens Coating System
  • Nitrogen-Filled Water and Fogproof
  • Lightweight Aluminum-Alloy Chassis
  • Compact Tabletop Tripod with Head
  • Carrying Bag with Strap
  • Utilizing a generous 60mm objective lens and their Advanced MultiGuard lens coating system boosts its performance in low and challenging conditions while ensuring the views remain bright and clear, even when the magnification is dialed all the way up. Its broad zoom range allows you to enjoy a 104-foot field of view and more easily scan the landscape for targets at the low 15x with the ability to quickly dial up the power to 45x and make detailed observations of distant subjects.

    The chassis is made of a lightweight and durable aluminum alloy that is protected by a black rubber armor. The chassis is nitrogen filled and O-ring sealed to be waterproof and resistant to internal fogging even in extreme weather and temperature conditions. The angled-viewing configuration sets the eyepiece at a 45° angle to the scope's body, which places your head in a more comfortable viewing position versus straight-through viewing models. A 1/4"-20 mount makes it compatible with many tripods, quick release plates, and other popular support systems like window mounts, and Vanguard includes a compact tabletop tripod to get you observing right out of the box. A lightweight carrying bag makes it easy to take with you in the field.

    Optical Performance

    • Broad 15-45x zoom eyepiece allows you to make observations at low power with the ability to zoom in for detailed views
    • Large 60mm objective lens helps to ensure views remain bright and clear, even when viewing subjects at long range on maximum magnification and in challenging light conditions
    • Advanced MultiGuard coating system: Proprietary formula for their fully multi-coated optics maximizes light transmission to produce bright and clear high-contrast images with accurate color and improved resolution
    • 104-foot field of view at 1000 yards at 15x power, 63-foot at 45x

    Use and Handling

    • The eyepiece is set at a 45° angle to the optical tube, placing the user's head in a comfortable viewing position while standing, sitting, or lying prone
    • Precise internal focusing mechanism
    • Fold-down rubber eyecup for comfortable use with or without eyewear
    • Standard 1/4"-20 mount is compatible with most quick release plates, heads, and photo/video/field tripods and other support systems
    • Long 21-16mm eye relief allows the user to back off the eyepiece to reduce eye fatigue and increase viewing comfort during long glassing sessions—even on high magnification
    • 4mm exit pupil at 15x magnification will completely cover most pupils as they open and dilate in low light

    Construction Details

    • Lightweight and durable aluminum-alloy chassis
    • Black rubber armor protects the optical tube from impacts and bumps while providing a sure grip during setup and breakdown—even in cold and wet conditions
    • Optical tube is nitrogen filled and O-ring sealed to be waterproof and resistant to internal fogging in extreme conditions
    • Compact design measures just over 10" in length
    • Tabletop tripod included
    • Lightweight carrying bag holds the spotting scope and tripod for easier carrying to the range or in the field

    Tripod

    • Two leg sections make it extremely compact—just 9" folded
    • Simple twist locks for easy setup and breakdown
    • Padded feet provide slip-resistant footing
    • Maximum height 9.8" and supports up to 5.5 pounds
    • Includes pan/tilt head with control handle
    • Weighs less than 1 pound

    Viewing Angle

    Angled

    Magnification

    15 to 45x

    Objective Lens Diameter

    60 mm

    Field of View

    15x: 104.4' @ 1000 yd / 34.7 m @ 1000 m
    45x: 62.6' @ 1000 yd / 20.8 m @ 1000 m

    Minimum Focus Distance

    8.0 m
    9.0 m

    Exit Pupil Diameter

    15x: 4 mm
    45x: 1.3 mm

    Eye Relief

    21.0 to 16.0 mm

    Fogproof

    Yes, Nitrogen Filled

    Water Resistance

    Waterproof

    Tripod Mounting Thread

    1/4"-20 Female

    Dimensions

    L: 26.4 cm

    Weight

    1296.0 g

    Brand: Vanguard | Code: V246123
    APN: 4719856246123 | Supplier Code: V246123

    Brand: Vanguard | Code: V246123
    APN: 4719856246123 | Supplier Code: V246123

    At a glance

  • 45° Angled Viewing
  • 15-45x Zoom Eyepiece
  • 60mm Objective Lens
  • Advanced MultiGuard Lens Coating System
  • Nitrogen-Filled Water and Fogproof
  • Lightweight Aluminum-Alloy Chassis
  • Compact Tabletop Tripod with Head
  • Carrying Bag with Strap
